Guangdong Sunkings Electric Co., Ltd
| Place of Origin: | China |
|---|---|
| Brand Name: | SHX |
| Certification: | CE/ISO9001/Saber/COC/EPA |
| Model Number: | SHX2500 |
| Minimum Order Quantity: | 1set |
| Price: | usd 327000 one set |
| Packaging Details: | pack by Plyfilm |
| Delivery Time: | 60 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 1000sets one year |
| Engine: | UK Perkins | Fuel Consumption: | 0.22L/KW.H |
|---|---|---|---|
| Noise Level: | 85dBA@7m(no Load) | Cooled Type: | Radiator/water And Fan |
| Engine Model: | 4016-61TRG3 | Rated Voltage: | 230V/400V |
| High Light: | 2500kva Emergency Diesel generator,emergency diesel generator power plant,Heavy Duty 2500kva generator |
||
2500kva Perkins Heavy duty electric power plant Emergency Diesel generator
| Engine Model | 4016-61TRG3 |
| Number of Cylinders | 6 cylinders |
| Cylinders arrangement | Vertical in line |
| Cycle | 4 stroke |
| Aspiration | Naturally |
| Bore×Stroke | 160mm x 190mm |
| Displacement | 61.123L |
| Compression ratio | 13:1 |
| Prime Power/Speed | 2000KW/1500rpm |
| Standby Power/Speed | 2200KW/1500rpm |
| Speed Governor | Electrical |
| Cooling System | Forced water cooling cycle |
| Steady speed droop | ≤1% |
| Total lubrication system capacity | 237.2L |
| Fuel Consumption at 100% Load | 211g/kWh |
| Starter Motor | DC24V |
| Alternator | DC24V |
| Alternator brand | Stamford, Marathon, Leroy Somer, Mecc-alte, TWGII… |
| Prime power | 2500 KVA |
| Frequency/speed | 50HZ/1500RPM |
| Exciter type | Single bearing, Brushless, Self-excited |
| Power factor | 0.8 |
| Voltage adjust range | ≥5% |
| Voltage regulation NL-FL | ≤±1% |
| Insulation Grade | H |
| Protection Grade | IP23 |
1. Diesel engines we can supply are including Cummins, Perkins, Volvo, MTU, Mitsubishi, Baudouin, Deutz and China Yuchai, Weichai, SDEC, Yangdong, etc.
2. Alternators we can supply are including Stamford, Marathon, Leroy Somer, ABB, Mecc Alte, Farrand, etc. We also can provide OEM and ODM for alternators.
3. Controllers we can supply are including Deepsea, PCC, ComAp, Smartgen, Datakom, etc. Automatical or manual control, ATS, AMF, Synchronizing, Remote monitor system are optional
