750kva Soundproof Standby Diesel Generator 600kw Cummins Genset

750kva Soundproof Standby Diesel Generator 600kw Cummins Genset

Brand Name: SHX
Model Number: SHX-825
MOQ: 1 Set
Price: Negotiable
Packaging Details: Standard export packing
Payment Terms: T/T, L/C
Detail Information
Place of Origin:
China
Certification:
ISO9001:2015, CE
Engine Brand:
Cummins
Alternator Brand:
Leroy Somer
Controller:
Deep Sea DSE6120
Cooling Method:
Water Cooled With Radiator
Fuel System:
Direct Injection
Starting Method:
By Batteries
Color:
Customers' Request
Noise Level:
80db At 7 Meter
Supply Ability:
150 Sets per year
Highlight:

Soundproof Standby Diesel Generator

,

750kva Standby Diesel Generator

,

600kw Cummins Genset

Product Description

750kva Soundproof Standby Diesel Generator 600kw Cummins Genset Most Widely Used



Supply Scope of silent generator

1.Standard tool kits and complete operation/maintenance/spare parts manuals to Engine/Alternator
2.Brand-new engine, with start motor.
3.Brand new brushless alternator, single bearing, flange connection, IP21-23, H insulation class, with AVR.
4.Auto control panel, with LCD display.
5.Engine mounted battery-charging alternator.
5.Circuit Breaker, Exhaust Silencer
6.Radiator for 50°C ambient temperature and double-deck cooling, with fan guard and front guard.
7.Anti-vibration pads are fixed between engine/alternator and base frame, as to ensure the compete genset

running under stabilization.
8.Skid-mounted bottom Fuel tank - 8hrs continuous running for choice (bigger fuel tank by your demand under extra cost)
9.External recessed emergency stop button for extra safety
10.The colors & Brands by your requests
11.Optional choice: ATS (automatic transfer switch), battery charger of mains supply, fuel-water separator, water heater and

oil heater ( depends on using environment),fuel filter, oil filter, water filter and air filter, Parallel system for your choice.



Genset Specifications

Genset model SHX-825
Genset rated power 600KW/750KVA
Rated voltage 400/230V (adjustable)
Rated current 1083A
Frequency 50Hz
Power factor 0.8 Lagging
Connecting type 3 phase 4 wire
Cooling system Closed cycle water-cooled with radiator
Overall dimension (L×W×H) mm 5600×2200×2560
Weight (kg) 9400
Diesel Engine
Brand Cummins
Model KT38-GA
Engine type 12 cylinders in vee, 4 stroke, air-to-air aftercooled
Aspiration Turbocharged
Rotating speed 1500 RPM
Engine cooling system Water-cooled
Speed governing system Electronic speed governor
Starting method By 24V batteries
Engine filter system Dry type air filter ,fuel filter, oil filter, water filter
Displacement (L) 38
Bore×Stroke (mm) 159×159
Compression ratio 13.9: 1
100% Load fuel consumption (g/kw.h) ≤206
Lube capacity (L) 114
Alternator
Brand Farrand
Model FLD634B
Excite type Brushless self-excited AVR regulation
Connecting type 3 phase 4 pole
Steady frequency change 0.50%
No load voltage ≥95%-105%
Steady voltage ≤±1%
Insulation class Class H
Protection grade IP23
The components of the genset
(1) Diesel engine; (2) Alternator; (3) Radiator assembly; (4) Control panel; (5) Base frame; (6) Canopy.



750kva Soundproof Standby Diesel Generator 600kw Cummins Genset 0



Continuous Generator

These generators operate year-round and are usually located in areas far away from the power grid or near

industrial and mining enterprises to meet the needs of construction, production and domestic electricity.

At present, in the area with more developed economy, because the construction of electric power network is

less than the power demand of users, the commonly used diesel generator set with short construction cycle

is set up to meet the needs of users.This type of generator has a relatively large capacity, provides continuous

power supply for unsteady loads, has no limit on the duration of continuous operation, and allows one hour of

over-load power supply for a period of 12 hours.The overload capacity is 10% of the rated output power of diesel

generator set. Because of its long running time and heavy load, the allowable power relative to the limit power of

this unit is set to a lower point.



750kva Soundproof Standby Diesel Generator 600kw Cummins Genset 1



OEM Service:

Guangdong Sunkings Electric Co., Ltd. Can provide professional OEM Service for customers.

1. Unique design and manufacture of generator according to customer’s requirement.

2. Customer logo printing or painting on the genset.

3. Installation and Operation manual neutral or headings can be design according to customer’s requirement.

4. Full warranty cover to support the customers.
