Guangdong Sunkings Electric Co., Ltd
| Place of Origin: | China |
|---|---|
| Brand Name: | SHX |
| Certification: | ISO, CE, Soncap, EPA |
| Model Number: | SCF-1000 |
| Minimum Order Quantity: | 1 set |
| Price: | USD 60000-80000USD |
| Packaging Details: | Plyfilm or plywood |
| Delivery Time: | 25 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 20 Sets per Month |
| Type: | Silent/Open/Trailer/Canopy/Container | Controller: | Deepsea/Smartgen/etc |
|---|---|---|---|
| Color: | Yellow Or According To Customer's Requirement | Fuel Tank: | Base Fuel Tank/External FueL Tank |
| Cooling Method: | Water Cooling | Protection Class: | IP21-23 |
| Highlight: | 1000kva Diesel Generator Set,3 Phase Diesel Generator Set |
||
| Genset Data | Brand | SHX | ||||||
| Frequency | 50Hz , 1500rpm | |||||||
| Voltage | 220/380V | |||||||
| Start mode | Electric | |||||||
| Phase & wires | 3 phase 4 wires | |||||||
| Power factor | COSΦ=0.8(lagging) | |||||||
| Protection | Low oil-pressure, High water temperature, Over-speed, Over-current., High Coolant temperature, Over load, Over/under/unbalance voltage. | |||||||
| Fuel Consumption | 205 L/h (100% load)@prime load | |||||||
| Engine Data |
Brand | Cummins | ||||||
| Model | KTA38-G5 | |||||||
| Frequency & Speed | 50Hz , 1500rpm | |||||||
| Bore*Stroke | 159*159mm | |||||||
| Cylinders | 12/V | |||||||
| Standard diesel type | 0# light diesel | |||||||
| Lubricant Oil | 15W40-CF4 Upgrade | |||||||
| Inter-Cooling | water cooled | |||||||
| Overload | 110% | |||||||
| Start mode | DC24V electric start | |||||||
| Displacement (L) | 37.8 | |||||||
| Alternator Data |
Brand | Farrand | ||||||
| Frequency & Speed | 50Hz , 1500rpm | |||||||
| System | Brushless, Self-excited, Synchronous, Single bearing | |||||||
| Insulation & Protection | H, IP23 | |||||||
| Materials | 100% copper | |||||||
| Voltage Regulator | AVR | |||||||
● Prime Power : Prime power is available for an unlimited number of annual hours in variable load application, in accordance with GB/T2820-97(eqvISO8528); A 10% overload capability is available for a period of 1 hour within a 12-hour period of operation.
● Standby Power : The standby power rating is applicable for supplying emergency power for the duration of a utility power interruption. No overload allowed, utility parallel or negotiated outage operation capability is available at this rating.
