Guangdong Sunkings Electric Co., Ltd
| Place of Origin: | China |
|---|---|
| Brand Name: | SHX |
| Certification: | ISO, CE, Soncap, EPA |
| Model Number: | SCF-2500 |
| Minimum Order Quantity: | 1 set |
| Price: | USD 150000-200000USD |
| Packaging Details: | Plyfilm or plywood |
| Delivery Time: | 25 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 20 Sets per Month |
| Type: | Silent/Open/Trailer/Canopy/Container | Controller: | Deepsea/Smartgen/etc |
|---|---|---|---|
| Color: | Yellow Or According To Customer's Requirement | Fuel Tank: | Base Fuel Tank/External FueL Tank |
| Cooling Method: | Water Cooling | Protection Class: | IP21-23 |
| Highlight: | Open 2500kva Cummins Diesel Generator,Three Phase 2500kva Cummins Diesel Generator,Auto Start 2500kva Cummins Diesel Generator |
||
| Genset Data | Brand | SHX | |||||
| Frequency | 60Hz, 1800rpm | ||||||
| Voltage | 380V | ||||||
| Start mode | Electric | ||||||
| Phase & wires | 3 phase 4 wires | ||||||
| Power factor | COSΦ=0.8(lagging) | ||||||
| Protection | Low oil-pressure, High water temperature, Over-speed, Over-current., High Coolant temperature, Over load, Over/under/unbalance voltage. | ||||||
| Fuel Consumption | 471 L/h (100% load)@prime load | ||||||
| Engine Data |
Brand | Cummins | |||||
| Model | QSK60-G7 | ||||||
| Frequency & Speed | 60Hz, 1800rpm | ||||||
| Bore*Stroke | 159*190 mm | ||||||
| Standard diesel type | 0# light diesel | ||||||
| Lubricant Oil | 15W40-CF4 Upgrade | ||||||
| Inter-Cooling | water cooled | ||||||
| Overload | 110% | ||||||
| Start mode | DC24V electric start | ||||||
| Displacement | 60.2 L | ||||||
| Alternator Data | Frequency & Speed | 60Hz, 1800rpm | |||||
| System | Brushless, Self-excited, Synchronous, Single bearing | ||||||
| Insulation & Protection | H, IP23 | ||||||
| Materials | 100% copper | ||||||
| Voltage Regulator | AVR | ||||||
| Control System |
Control System | Deep Sea 7320 | |||||
| Two language interface: Chinese & English | |||||||
| Start or Stop Generator set manually / automatically; Open controller output can be defined as Pre-heat/Idle output. | |||||||
| High Coolant temperature protection; Low Oil pressure protection. Over speed protection | |||||||
| Over load protection; Generator over/under frequency protection: Generator over/under/unbalance voltage Protection | |||||||
Standard Parts:
Brand new Cummins electric governor diesel engine and Leroy-somer brushless self exciting 100% copper alternator.
Intelligent LED display control panel;
Speed governor & MCCB
Electric start and 24v charger;
Standard air filter, oil filter, fuel filter; Cooling water tank;
High-efficient silencer
Exhaust elbow
Steel base-frame against vibration;
Soft pipe for fuel and handle for lube going-out;
Operation& Maintenance manual.
Battery Charger.
Optional Parts:
1, Jacket water heater
2, Oil heater
3, Diesel heater
4, Trailer 5, ATS
